לוח ASUS B760-PLUS WIFI ING LGA1700 USB3.2 90MB1ER0

Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**

• Refer to www.asus.com for CPU support list.
  • Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
    Chipset
    Intel® B760 Chipset
    Memory
    4 x DIMM, Max. 128GB, DDR5 Non-ECC, Un-buffered Memory*
    Dual Channel Memory Architecture
    Supports Intel® Extreme Memory Profile (XMP)
    OptiMem II
• Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support under the Support tab or visit https://www.asus.com/support/
• Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
  Graphics
  1 x DisplayPort**
  1 x HDMITM port***
• Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
  • Supports max. 4K@60Hz as specified in DisplayPort 1.4.
    • Supports 4K@60Hz as specified in HDMITM 2.1.
      Expansion Slots
      Intel® 13th & 12th Gen Processors
      1 x PCIe 5.0 x16 slot
      Intel® B760 Chipset
      1 x PCIe 3.0 x16 slot (supports x4 mode)*
      2 x PCIe 3.0 x1 slots*
• PCIEX16 shares bandwidth with PCIEX11 and PCIEX12 . When PCIEX11 or PCIEX1_2 runs at PCIe x1 mode, PCIEX16 will only run at PCIe x2 mode.
  - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
  Storage
  Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*
  Intel® 13th & 12th Gen Processors
  M.21 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  Intel® B760 Chipset
  M.22 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
  M.23 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
  4 x SATA 6Gb/s ports
• Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
  Ethernet
  1 x Realtek 2.5Gb Ethernet
  TUF LANGuard
  Wireless & Bluetooth
  Wi-Fi 6
  2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
  Supports 2.4/5GHz frequency band
  Bluetooth® v5.2*
  *The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer’s website for the latest specifications."
  USB
  Rear USB (Total 6 ports)
  1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®)
  1 x USB 3.2 Gen 2 port (1 x Type-A)
  3 x USB 3.2 Gen 1 ports (3 x Type-A)
  1 x USB 2.0 port (1 x Type-A)
  Front USB (Total 7 ports)
  1 x USB 3.2 Gen 2 connector (supports USB Type-C®)
  1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
  2 x USB 2.0 headers support 4 additional USB 2.0 ports
  Audio
  Realtek 7.1 Surround Sound High Definition Audio CODEC
  - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  - Supports up to 24-Bit/192 kHz playback
  Audio Features
  - Audio Shielding
  - Rear optical S/PDIF out port
  - Premium audio capacitors
  - Dedicated audio PCB layers
  - Audio cover
  Back Panel I/O Ports
  1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®)
  1 x USB 3.2 Gen 2 port (1 x Type-A)
  3 x USB 3.2 Gen 1 ports (3 x Type-A)
  1 x USB 2.0 port (1 x Type-A)
  1 x DisplayPort
  1 x HDMITM port
  1 x Wi-Fi Module
  1 x Realtek 2.5Gb Ethernet port
  5 x Audio jacks
  1 x Optical S/PDIF out port
  Internal I/O Connectors
  Fan and Cooling related
  1 × 4-pin CPU Fan header
  1 × 4-pin CPU OPT Fan header
  1 × 4-pin AIO Pump header
  4 × 4-pin Chassis Fan headers
  Power related
  1 × 24-pin Main Power connector
  1 × 8-pin 12V Power connector
  1 × 4-pin +12V Power connector
  Storage related
  3 x M.2 slots (Key M)
  4 x SATA 6Gb/s ports
  USB
  1 x USB 3.2 Gen 2 connector (supports USB Type-C® )
  1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
  2 x USB 2.0 headers support 4 additional USB 2.0 ports
  Miscellaneous
  3 x Addressable Gen 2 headers
  1 x Aura RGB header
  1 x Clear CMOS header
  1 x COM Port header
  1 x Front Panel Audio header (AAFP)
  1 × 20-3 pin System Panel header with Chassis intrude function
  1 x Thunderbolt™ (USB4®) header
  Special Features
  ASUS TUF PROTECTION
  - DIGI VRM (- Digital power design with DrMOS)
  - ESD Guards
  - TUF LANGuard
  - Overvoltage Protection
  - SafeSlot Core+
  - Stainless-Steel Back I/O
  ASUS Q-Design
  - M.2 Q-Latch
  - Q-DIMM
  - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
  - Q-Slot
  ASUS Thermal Solution
  - M.2 heatsink
  - VRM heatsink design
  ASUS EZ DIY
  - CPU Socket lever protector
  - ProCool
  - Pre-mounted I/O shield
  - SafeSlot Core+
  - SafeDIMM
  Aura Sync
  - Aura RGB header
  - Addressable Gen 2 headers
  Software Features
  ASUS Exclusive Software
  Armoury Crate
  - Aura Creator
  - Aura Sync
  - Fan Xpert 4
  - Power Saving
  - Two-Way AI Noise Cancellation
  AI Suite 3
  - DIGI+ VRM
  - PC Cleaner
  TUF GAMING CPU-Z
  DTS Audio Processing
  MyASUS
  Norton 360 for Gamers
  WinRAR
  UEFI BIOS
  ASUS EZ DIY
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  - ASUS UEFI BIOS EZ Mode
  BIOS
  128 Mb Flash ROM, UEFI AMI BIOS
  Manageability
  WOL by PME, PXE
  Accessories
  Cables
  2 x SATA 6Gb/s cables
  Miscellaneous
  1 x ASUS Wi-Fi moving antenna
  1 x TUF Gaming sticker
  2 x M.2 Rubber Packages
  1 x Screw package for M.2 SSD
  Documentation
  1 x TUF Certification card
  1 x User guide
  Operating System
  Windows® 11, Windows® 10 64-bit
  Form Factor
  ATX Form Factor
  12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
